Fibaro | Double Smart Module, Z-Wave Plus EU
1 × 50.81 €
Fibaro | Smart Module, Z-Wave Plus EU
49.18 €
Producer product family: Smart Module, Z-Wave Plus EU
Producer: Fibaro
1 laos
| Gross depth (mm) | 65.00 |
|---|---|
| Gross height (mm) | 65 |
| Gross weight | 0.05 |
| Gross width (mm) | 31 |
| Net weight | 0.02 |
| Packing quantity | 1.00 |
| Paper/Pasteboard | 20.00 |
| Plastic (No PET) | 10.00 |
| Tare weight (kg) | 0.03 |
| Volume (m3) | 0.000130975 |
| Embeeded battery | No |
| WEEE tax | No |
| Tehnilised omadused | Power supply: 100-240V; Smart Module (FGS-214): 6.5A, Double Smart Module (FGS-224): 6A per one channel, 9.5A total; Compatible with resistive or incandescent load; Active element: micro-gap relay μ; Maximum length of wires: 3 m; Recommended 0.2–2.0 mm2 wire cross-section area; 0–35°C operating temperature; Ambient humidity: 0–95%; Radio protocol: Z-Wave (500 series chip); Radio frequency band: 868.0–868.6 MHz; 869.7–870.0 MHz; Max. transmitting power: +5dBm; Range: up to 50 m outdoors, up to 40m indoors; Dimensions (Height x Width x Depth): 42.5 x 38.25 x 20.3 mm; Automatic electrical control for use in equipment for household or similar use; Mode of operation: Type 1.B Action; Pollution degree: 2; A Software class; Compliance with EU directives: 2011/65/EU, 2015/863, 2014/53/EU |
| Muud funktsioonid | The remotely operated FIBARO Smart Module and Double Smart Module are designed to turn electrical devices or circuits on and off; Smart Module (FGS-214) allows to control one device or circuit and the Double Smart Module (FGS-224) allows to control two devices or circuits; The compact size of the device allows for the product to be installed in the housings of other devices. The devices can be controlled either via the Z-Wave network or with buttons connected directly to them |
| Eritunnused | Works with various types of switches and buttons; Supports Z-Wave network Security Modes: S0 with AES-128 encryption and S2 Authenticated with PRNG-based encryption; Works as a Z-Wave signal repeater (all non-battery operated devices within the network will act as repeaters to increase reliability of the network); May be used with all devices certified with the Z-Wave Plus certificate and should be compatible with such devices produced by other manufacturers |
| Producer product family | Smart Module, Z-Wave Plus EU |
| Palette Qty | 13193 |
| Producer | Fibaro |
| Warranty | 24 |
